TAMURA MACHINE INDUSTRY INC.

59-4, Hirakawa Nakamichi Omote, Joyo, Kyoto 610-0101, Japan
Phone:81-774-52-3800
FAX:81-774-52-0088
AUTOMATIC LABELING MACHINE (EXPERT LABELER)AUTOMATIC LABELING MACHINE (EXPERT LABELER)

AUTOMATIC LABELING MACHINE (EXPERT LABELER)

TAMURA MACHINE INDUSTRY INC.

FEATURES

– Usable to many kinds of containers/reasonable price.
– Multi-purpose stand-alone machine.
– Capable of also being used on the product line in the future.
– Highly effective for large-variety and low-volume production.
– Needs few parts-changes depending on the kinds of goods.
– Capable of quickly cope with urgent production.
– No needs for parts-charge for any kind of straight-body containers.
– Capable of handling plastic containers having different diameters at the two ends.
– Capable of doing fixed- position pasting for plastic containers with grips.
– Capable of easily adjusting label-pasting position by a handle lever.
– Pasting to Ravel bothends is possible.(Option specification)
– Capable of handling containers of polygonal shape.
– Unbeatable compact size.

SPECIFICATIONS and NOTES

– Machine type: LVRLS-3515
– Applications: Round bottles
– Handling capacity: 45 containers/min
– Usable containers: Glass, PET, PET with grip, polygonal, and others
– Label width: 25 ~ 150mm
– Label length: 55 ~ 350mm
– Container’s diameter: 40 ~ 110mm
– Strength of the conveyer: 2,150mm (standard)
– Option: Function to fix labelling place, function of pasting at both ends of a label, a turntable for supplying containers, a turntable for taking out containers, function for putting a label around a polygonal container
– Power supply: AC 200V, 3 phase 50/60Hz
– Power consumption: 0.9kW
– Compressed air: Pressure 0.5MPa, 50 L/min please prepare
– Machine size: About 2,150(W) / 925(D) / 1,600(H)mm
(It’s changed depending on the specification)

TAMURA MACHINE INDUSTRY INC.

59-4, Hirakawa Nakamichi Omote, Joyo, Kyoto 610-0101, Japan
Phone:81-774-52-3800
FAX:81-774-52-0088
CORPORATE PROFILE
SEMI-AUTOMATIC LABELING MACHINES "LABEL MAN" SERIES<br />(Labeling Machines)SEMI-AUTOMATIC LABELING MACHINES "LABEL MAN" SERIES<br />(Labeling Machines)

SEMI-AUTOMATIC LABELING MACHINES "LABEL MAN" SERIES
(Labeling Machines)

TAMURA MACHINE INDUSTRY INC.

FEATURES

– It’s very easy to change labels and containers.
– Labeling position (height) on a container is fixed.
– If the container’s body is straight, according to the label position (height), a label is pasted on a part of a vessel or all around of a container.
– This machine is usable to glass or plastic containers, metal cans, paper pipes, special formed containers, etc.
– Any kind of this machine has a rack and casters, so you are capable of move it easily.

SPECIFICATIONS and NOTES

– Applications:Round bottles
– Kind of machine: Glue and paste type, BRL-3515
– Label pasting points: 1 point (front)
– Label: Cut label
– Label length: 40 ~ 350mm
– Label width: 25 ~ 150mm
– Handling ability: 20 ~ 30 containers/min (depending on the operator’s ability)
– Type of paste: starch or chemical paste
– Max. diameter of a container: 110mm
– Max. length of a container: 400mm
– Sealing function: Option
– Printing style: Color emboss
– Height of printing character: 2 or 3mm
– Printing digits and lines: 12 digits – 1 or 2 lines
– Machine size: 680(W) / 570(D) / 1000(H)mm*
– Power supply: AC 100 plus or minus 10V (200V is option) 50/60Hz
– Power consumption: 800VA
– Machine weight: About 150kg
– Labelling accuracy
Height: within plus or minus 1mm
Lean: plus or minus 1.5mm (difference between one end and other of label)
* Machine size differs depending on the specification.

TAMURA MACHINE INDUSTRY INC.

59-4, Hirakawa Nakamichi Omote, Joyo, Kyoto 610-0101, Japan
Phone:81-774-52-3800
FAX:81-774-52-0088
Corporate Profile
PRODUCTS MANUAL SUPPLY TYPE SEMI-AUTOMATIC CARTONING MACHINE<br />KDM-300 SERIES (Cartoning Machines)PRODUCTS MANUAL SUPPLY TYPE SEMI-AUTOMATIC CARTONING MACHINE<br />KDM-300 SERIES (Cartoning Machines)

PRODUCTS MANUAL SUPPLY TYPE SEMI-AUTOMATIC CARTONING MACHINE
KDM-300 SERIES (Cartoning Machines)

TAMURA MACHINE INDUSTRY INC.

FEATURES

– Maximum production capacity of 60 pieces/minute can be done by one (1) operator only.
– Super compact machine can be moved and installed anywhere you want.
– This machine can be used for paper and plastic carton.
– Easy and speedy tooling change-over due to change of products.
– The cartoning machine can be used as carton box producing machine too.
– Production speed can be adjusted freely.

SPECIFICATIONS and NOTES

– Applications
Small bottles (for seasonings, etc.), cartons, stick candies (confectionery), etc.
– Types of products
Small bottles (for seasonings, etc.), cartons, stick candies (confectionery), etc.
– Operating speeds
25 cartons/min
– Packaging materials
Blank sheet (cardboard)
– Dimensional range of products
75 ~ 200(L) × 100 ~ 200(W) × 50 ~ 200(Thickness)mm
– Sealing method
Hot-melt glue
– Machine dimensions
3,500(L) × 1,120(W) × 1,450(H)mm
– Machine dimensions
1,500kg
– Power consumption
Three-phase, 200V, 7.5kW
– Air consumption
0.5MPa, 200 L(Normal)/min

TAMURA MACHINE INDUSTRY INC.

59-4, Hirakawa Nakamichi Omote, Joyo, Kyoto 610-0101, Japan
Phone:81-774-52-3800
FAX:81-774-52-0088
Corporate Profile
